Narva - 60292BL
Waterproof Heavy Duty Toggle Switch Off/On DPST - 25A @ 12V
Waterproof Heavy Duty Toggle Switch Off/On DPST - 25A @ 12V
Regular price
$69.95 AUD
Regular price
Sale price
$69.95 AUD
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The Narva Waterproof Heavy Duty Toggle Switch is built to withstand tough conditions, making it the ideal choice for automotive, marine, and off-road applications across Australia. Featuring a durable DPST design, it offers reliable On/Off switching with a 25A rating at 12V (15A at 24V).
Fully sealed with epoxy resin to IP67 standards and fitted with an integrated O-Ring seal, this switch ensures long-lasting performance even in harsh environments. Compact yet robust, it’s designed for easy installation with a 12mm mounting opening and push-on terminals.
Key Features
- Heavy duty DPST Off/On toggle switch
- Rated 25A at 12V and 15A at 24V
- Fully sealed with epoxy resin to IP67 waterproof standard
- Integrated O-Ring seal for extra durability
- Wide operating temperature: -40°C to +85°C
- Push-on terminals for quick connection
- Compact 12mm mounting opening
Specifications
Warranty | 1 Year |
Voltage | 12/24V |
Power Rating | 25A @ 12V, 15A @ 24V |
Switch Action | Off – On (DPST) |
Number of Terminals | 4 |
Number of Poles | 2 |
Number of Positions | 2 |
Switch Type | Toggle |
Illumination | Non-Illuminated |
Operating Temp. | -40°C to +85°C |
Protection Rating | IP67 (Epoxy Resin Sealed) |
Mounting Opening | 12mm diameter |
Weight | 0.05kg |
