Amptron - AT-240-1215ALFPV01
12V 15A LiFePO₄ AC‑DC Battery Charger with Wake-Up Feature
12V 15A LiFePO₄ AC‑DC Battery Charger with Wake-Up Feature
Couldn't load pickup availability
The Amptron 12V 15A Lithium Battery Charger is purpose-built for charging LiFePO₄ batteries safely, efficiently, and reliably. Perfect for off-grid solar systems, caravans, 4WD setups, and marine applications across Australia, this charger offers a dedicated lithium charging profile and up to 15 amps of clean, stable output.
Designed to restore depleted batteries quickly, the charger includes a wake-up feature that activates batteries with low or near-zero voltage — common in over-discharged conditions. It also features full protection circuitry, compact construction, and compatibility with Australian mains power (200–264V AC). Whether you’re topping up a single battery or maintaining a backup system, this charger is built to perform.
Key Features
- Optimised for LiFePO₄ – Delivers a precise charging profile for 12V lithium batteries
- 15A Output Current – Fast, stable charging for deep-cycle LiFePO₄ setups
- Mains Compatible (200–264V AC) – Ideal for Australian power outlets
- Battery Wake-Up Function – Revives deeply discharged or protected batteries
- Comprehensive Protections – Built-in over-voltage, over-current, short-circuit, and reverse polarity safeguards
- Auto-Recovery – Charger restarts automatically after fault conditions are resolved
- Efficient Performance – Up to 80% charging efficiency at full load
- Compact Footprint – Lightweight, wall- or bench-mountable design
- RCM Certified – Meets Australian electrical compliance standards
- Secure Connection – M8 ring terminals ensure solid battery attachment
Specifications
Model | AT‑240‑1215ALFPV01 B |
Battery Type | Lithium Iron Phosphate (LiFePO₄) |
Nominal Battery Voltage | 12V DC |
Output Voltage Range | 14.4 – 14.8V DC |
Output Current | 15A (±5%) |
Input Voltage | 200 – 264V AC, 50/60Hz |
Input Power | Max 267W |
Ripple Voltage | ≤ 250mV |
Charging Efficiency | Up to 80% |
Battery Wake-Up | Yes (automatic activation) |
Safety Protections | OVP, OCP, SCP, Reverse Polarity |
Connector Type | M8 Ring Terminals |
Mounting Style | Foot mount with side brackets |
Dimensions (L x W x H) | Approx. 170 x 90 x 55mm |
Weight | ~1.3kg (packaged) |
Certification | RCM Certified (Australia) |
